The AIRA HKV Model Bi-Directional Knife Edge Gate Valve is designed for reliable flow isolation and shut-off in both directions. Its knife-edge gate design supports effective closure, making it a practical solution for industrial applications where dependable sealing and consistent operation are essential.
Specification & Standard
Size Range
50MM To 600MM
Temperature Range
Upto 250°C
Working Pressure
Upto 40 Kg/cm²
Flange End
ANSI B 16.5 (150#) / EN 1092-2 PN-10
Seat
NBR / EPDM / VITON / PTFE / METAL
Flow
Bi Directional
Leakage Class
Class VI
Design & Manufacturer
MSS SP-81
Body Material
C.I / S.G.I / WCB / CF8 / CF8M
Gate
S.S.304 / 316 / 316L / M.S. / DUPLEX-2205
Operation
Handwheel / Cylinder / Cylinder With Manual Override / Gear Operated / Chainwheel Operated / Gear With Chainwheel Operated / Bare Shaft(Electric Actuator Operated)
Body Style
Single PC / Semi Lug / Full Lug / Double Flange & Semi Flange / Wafer Type
Stem Type
Rising
- Wide Size Range – Available in sizes from 50 mm to 600 mm.
- Multiple Material Options – Body options include CI/SGI, WCB, CF8 and CF8M.
- Versatile Seat Options – Available with NBR, EPDM, Viton and PTFE seats.
- Flexible Operation – Supports handwheel, cylinder, gear, chain wheel and electric actuation options.
- Temperature Capability – Rated up to 250°C, depending on the selected materials and seat configuration.
