The AIRA Square Slide Uni-Directional Knife Edge Gate Valve is designed for flow isolation in industrial systems with square openings. Its sliding gate opens or closes the flow passage, while the uni-directional design provides shut-off in the specified flow direction.
Specification & Standard
Size Range
Size Range:- 50x50MM To 2000x2000MM (Large Size On Request)
Temperature Range
Upto 250°C
Flange End
Square Type Our Std. (Other Flange Connection On Request)
Seat
NBR / EPDM / Viton / PTFE
Flow
Uni Directional
Leakage Class
5% Leakage
Design & Manufacturer
MSS SP-81
Body Material
M.S. Fabricated / S.S.304 Fabricated / S.S.316 Fabricated
Gate
S.S.304 / S.S.316 / S.S.316L / M.S. / DUPLEX-2205
Operation
Handwheel / Cylinder / Cylinder With Manual Override / Gear Operated / Chainwheel Operated / Gear With Chainwheel Operated / Bare Shaft(Electric Actuator Operated)
Body Style
Single PC / Square Type / Full Lug / Double Flange / Wafer Type
Uni-Directional Design – Designed for flow isolation in the specified direction.
Square Slide Design – Designed for industrial systems with square flow openings.
Uni-Directional Shut-Off – Provides isolation in the specified flow direction.
Sliding Knife Gate – Opens and closes the flow passage through linear gate movement.
Standard-Compliant Design – Designed and manufactured to MSS SP-81.
Multiple Seat Options – Available with NBR, EPDM, Viton or PTFE seats.
Get in touch with our team at +91 9099477256 to receive the Dimension Table
