The AIRA IBN Model Bi-Directional Knife Edge Gate Valve is designed to control flow and provide shut-off in both directions, with a knife-edge gate for handling demanding industrial media.
Specification & Standard
Size Range
50MM To 1200MM
Temperature Range
Upto 250°C
Working Pressure
Upto 6 Kg/cm²
Flange End
ANSI B 16.5 (150#) / EN 1092-2 PN-10
Seat
NBR / EPDM / VITON / PTFE / METAL
Flow
Bi Directional
Leakage Class
Class VI
Design & Manufacturer
MSS SP-81
Body Material
C.I / S.G.I / WCB / CF8 / CF8M
Gate
S.S.304 / 316 / 316L / M.S. / DUPLEX-2205
Operation
Handwheel / Cylinder / Cylinder With Manual Override / Gear Operated / Chainwheel Operated / Gear With Chainwheel Operated / Bare Shaft(Electric Actuator Operated)
Body Style
Single PC / Semi Lug / Full Lug / Double Flange & Semi Lug / Wafer Type
Stem Type
Rising
- Bi-Directional Sealing – Reliable shut-off in both flow directions.
- Stainless Steel Gate – Polished surface for effective sealing.
- Low Pressure Drop – Full-port design supports efficient flow.
- Anti-Clogging Body Design – Helps prevent solid accumulation.
- Corrosion-Resistant Coating – Epoxy finish protects the valve body.
Get in touch with our team at +91 9099477256 to receive the Dimension Table
