“aira” Offers Investment Casting WCB / CF8 / CF8M / CF3M Ball Valve Floating In Two Piece Design. Engineered For Multiple On/Off Operations In The Down Stream.
Specification & Standard
Design & Manufacturer
ASME B 16.34 / BS EN ISO 17292
Valve Face To Face Dimension
As Per Manufacturer Standard
Inspection And Testing
API 598/ ISO - 5208/ BS EN 12266 - 1
Size Range
1/2" To 12" Flanged
Media
Air/ Water/ Oil & Gas
Body Material
CAST IRON(CI), DUCTILE IRON(DI), S.G IRON(SGI), WCB, CF8, CF8M, CF3M , SS 304L , DUPLEX , HAST ALLOY, MONEL CF8, CF8M
Seat Material
PTFE, RPTFE, CFT, GFT, MODIFIED PTFE, AIRA-250, NYLON, DEVLON, PEEK
Flange Drilling
Asme B 16.5 Class 300#/ Din/ Jis
Leakage Class
ISO 5208 Class VI / FCI - 70- 2/ ASME, ANSI B 16,16.104"
End Connection
ISO 7-1 FOR BSPT / ASME B 1.201 FOR NPT FOR S/E
Temperature Range
PTFE : Upto 180°C / PEEK : 250°C RPTFE : Upto 220°C / AIRA250"
Pressure Class
300#
Ball Material
CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M
Ball Type
Hollow, Solid
Stem Material
Aisi 410, Ss 304, Ss 316, Ss 304l, Ss 316l, Duplex 2205, Duplex 2507, Monel
- High Cycle Life
- Antistatic Design & Fire Safe Design As Per API 607
- Blow Outproof Stem
- Locking Handle Available
- ISO 5211 Mounting Pad Available
- V-type Cheuron Gland Packing
- Which Leads To Zero Leak After Thousands of cycle
2 Piece
Flanged End Ball Valve 300#
2 Piece
Flanged End Ball Valve 300#
Dimension Table
