Approvals
“aira” Offers Automation And Manually Operated Flanged Ball Valves Feature A Compact, One Piece Body Design With Flanged Insert. The One Piece Body Suppliers Maximum Structural Strength While Minimizing The Number Of Potential Leak Paths. A Floating Ball Design Offers Low Torque And Increase Valve Cycle Life. These Rugged, Economical, End-entry Flanged Ball Valves Are The Ideal Solutions From The “aira” Product Line For Industrial Applications.
Specification & Standard
Design & Manufacturer
BS EN ISO 17292 / ASME B 16.34
Valve Face To Face Dimension
ASME B 16.10 - 300#
Inspection & Testing
API 598 / ISO-5208 / BS EN 12266-1
Temperature Range
PTFE : Upto 180°C / PEEK : 250° , RPTFE : Upto 220°C / AIRA250
Media
Air / Water / Oil & Gas
Ball Material
CF8, CF8M, WCB+ ENP, HAST ALLOY, DUPLEX, MONEL, CF3M
Stem Material
Aisi 410, Ss 304, Ss 316, Ss 304l, Ss 316l, Duplex 2205, Duplex 2507, Monel
Flange Drilling
Asme B 16.5 Class 300#/ Din/ Jis
Leakage Class
ISO 5208 Class VI / B16.104 , ANSI FCI 70-2( BUBBLE TIGHT SHUTOFF)
End Connection
ASME B 16.5 CLASS 300 FOR FLANGE END
Size Range
1/2" to 6" Flanged 300#
Pressure Class
300#
Body Material
CAST IRON(CI), DUCTILE IRON(DI), S.G IRON(SGI), WCB, CF8, CF8M, CF3M, SS 304L, DUPLEX, HAST ALLOY, MONEL
Ball Type
Hollow & Solid
Seat Material
PTFE, RPTFE, CFT, GFT, MODIFIED PTFE, AIRA-250, NYLON, DEVLON, PEEK
- Low Operating Torque
- Positive Shut Off
- Quick In Action
- Compact Design
- Longer Smooth Life
- Locking Handle Available
- Direct Mounting As Per ISO 5211
Single Piece
Flanged End Ball Valve 300#
Single Piece
Flanged End Ball Valve 300#
Dimension Table
