V- Knotch

Flanged End Ball Valve

Size Range
1" To 16" Flanged
Temperature Range
PTFE : Upto 180°C/ RPTFE-200
Working Pressure
Up to 10 Kg/Cm²
Inquiry Now

V- Knotch Flanged End Ball Valve

Size Range
1" To 16" Flanged
Temperature Range
PTFE : Upto 180°C/ RPTFE-200
Working Pressure
Up to 10 Kg/Cm²
Inquiry Now

Approvals

Aira Euro Automation is a manufacturer, exporter, and supplier of V Notch Ball Valve. V-Notch Ball valves are specially used to control the flow rate in pipelines because it has V-Notch inside the valve body. V Notch Ball Valve characterized V ball which is perfectly suited to give a full range of control applications with superior flow control. In small sizes, these control ball valves when compared to globe valves are more compact, lighter in weight, and much less expensive.

The V-Notch Ball Valve is also known as V Port Ball Valve and It can sustain up to 10Kg/Cm² pressure & temperature up to 180°C. We use PTFE seals, WCB/CF8/CF8M/CF3M materials used to make the Body, and CF8/CF8M/CF3M to make the Ball. Stainless Steel 304 has been used for the Gland plate, Gland L.N. Bolt, Trunnion pin, and bracket fitting bolts. For the Shaft and retainer, we use S.S. 304/S.S. 316. It has a class VI leakage type. It is available in 1” to 4” inches & has flanged ends 150# to 300#.

The 90 and 60 balls, like standard round hole balls, offer an equal percentage inherent flow characteristic. Medium angle V-Port 30 balls furnish a modified equal percentage inherent flow characteristic.

Specification & Standard

Design & Manufacturer

BS EN ISO 17292

Valve Face To Face Dimension

ASNI B16.10/ DIN 3202/ BS EN 558-1/2

Flange Standard Conformity

ASME B16.5 150#

Size Range

1" To 16" Flanged

Tempreature Range

PTFE : Upto 180°C/ RPTFE-200

Pressurre Class

150#, 300#

Stem Material

CF3, CF3M, CF8, CF8M, 410, DUPLEX 2205, DUPLEX 2507, 17-4 PH

Seat Material

M TO M,PTFE, RPTFE, CFT , GFT, MODIFIED PTFE, AIRA-250, NYLON, DEVLON

Add Features

Spring Loaded Design, Single Seated Design

Inspection & Testing

ASME/ FCI 70-2 Metal Seat For UNI-Direction Flow, Soft Seat

Top Flange Drilling

ASA 150#/ DIN 2632 & 2633/ BS EN 10 TABLE D,E,F (Coustomer Specifiel)

Media

Air/ Water/ Oil & Gas

Body Material

CAST IRON(CI), DUCTILE IRON(DI), S.G IRON(SGI), WCB, CF8, CF8M, CF3M, SS 304L, DUPLEX, HAST ALLOY, MONEL

Ball Material

CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M

Ball Type

Hollow & Solid

Flange Drilling

ASME B16.5 Class 150#

Certification

Pod

Features & Benefits

1- Soft Seat Valves Exceed Class VI Offering Bubble Tight Shut Off With Zero Leakage.

2- Precise Contouring Of The V-Notch Balls Provides A Nearly Equal Percentage Characteristic.

3- Replaceable Ball Seal & Backup Ring For Added Rigidity.

4- Ball Machined To A Super Smooth Finish, Hard Chrome Plated And Polished To Increase Ball Seal Life.

5- High CV To Body Size Ratio.

6- Spring Loaded Design.

7- Single Seated Design

Direct Mounting As Per ISO 5211

V- Knotch

Flanged End Ball Valve

Dimension Table

V- Knotch

Flanged End Ball Valve

Dimension Table
