2/2 Way

High Pressure Piston Flanged Solenoid Valve

Size Range
1/4" To 2" Flanged
Temperature Range
Upto 90°C
Working Pressure
2 To 40 Bar
Inquiry Now

2/2 Way High Pressure Piston Flanged Solenoid Valve

Size Range
1/4" To 2" Flanged
Temperature Range
Upto 90°C
Working Pressure
2 To 40 Bar
Inquiry Now

Approvals

“aira” Offers HIGH FLOW piston type solenoid valves, are specially engineered in the construction of Investment Cast CF8 / CF8M / CF3M body for multiple and long lasting operations, especially in STEAM & HIGH Temperature FLUIDS. Valves for the inflammable media / environment / Flameproof / Explosion Proof solenoid coil are available in such application.

Specification & Standard

Size Range

1/4" to 2" Flanged

Tempreature Range

Upto 90°C

Pressurre Class

0 To 5 Bar

End Connection

Flanged 150#

Certification

CE

Media

Hot Water / LD Oil / Air / Water / Corrosive Media

Body Material

CF8, CF3M, CF8M

Seat Material

PTFE, Viton, CFT

Flange Drilling

As Per 150#

Features & Benefits

1 – 2/2 Way Design: Provides on/off control with a two-port configuration for managing fluid flow.

2 – Normally Closed: Default position is closed when de-energized, opening only when actuated.

3 – Flanged Connections: Features flanged fittings for robust and secure installation, ideal for high-pressure and demanding applications.

4 – Durable Construction: Made from high-quality materials like stainless steel or brass, ensuring long-term reliability and resistance to corrosion.

5 – Automation Ready: Electrically actuated for precise and efficient control in automated systems.

6 – Versatile Fluid Compatibility: Suitable for a wide range of fluids, including air, water, and chemicals.

7 – Low Maintenance: Engineered for minimal upkeep, reducing maintenance needs and operational costs.

2/2 Way

High Pressure Piston Flanged Solenoid Valve

Dimension Table

2/2 Way

High Pressure Piston Flanged Solenoid Valve

Dimension Table
