Approvals
“aira” Offers Manual & Automation Operated Two Piece Design Floating Ball Valve, Engineered For Multiple On/ Off Operations In The Down Stream For Use In Oil & Gas Industry.
Specification & Standard
Design & Manufacturer
ASME B 16.34/ BS EN ISO 17292
Valve Face To Face Dimension
ASME B 16.10/ BS EN ISO 17292
Inspection & Testing
API 598/ ISO - 5208/ BS EN 12266- 1
Size Range
1/2" to 8" Flanged 300#
Fugitive Emissions
ISO 15848-1 A 2017
Ball Type
CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M
Ball Material
Solid For 300#
Stem Material
Aisi 410, Ss 304, Ss 316, Ss 304, Ss 316, Duplex 2205, Duplex 2507, Monel
Certification
Design CE, SIL3, IBR, Fire Safe, EIL Approved
Leakage Class
ISO 5208 Class VI/ FCI - 70- 2/ ASME, ANSI 16,16.104
End Connection
ASME B 16.5 CLASS 300#
Temperature Range
Upto 180°C
Pressure Class
300#
Media
Air/ Water/ Oil & Gas
Body Material
CAST IRON(CI),DUCTILE IRON(DI), S.G IRON(SGI), WCB, CF8, CF8M, CF3M, SS 304L, DUPLEX, HAST ALLOY, MONEL
Seat Material
PTFE, RPTFE, CFT, GFT, MODIFIED PTFE, AIRA-250, NYLON, DEVLON, PEEK, D-PLASTIC
Flange Drilling
Asme B 16.5 Class 300#
1- Blow- Out Proof Stem.
2- Dual Shaft Seals Eliminate Leakage.
3- Anti-Static Stem Device.
4- API 607 Fire Safe Design.
5- Mirror Finished Ball With Slot Vented Ball For Thermal Expansion.
2 Piece
High Performance Floating Ball Valve 300#
2 Piece
High Performance Floating Ball Valve 300#
Dimension Table
